What Wheels Fit?
Wheel and Bolt Pattern Cross Reference


Search Bolt Pattern by Make and Model

Make:
Model:

Browse Vehicles by Wheel Bolt Pattern



AMC EAGLE Wheel and Bolt Pattern 1988-92 AMC EAGLE PREMIER, ES (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore:

AMC EAGLE Wheel and Bolt Pattern 1988-92 AMC EAGLE PREMIER, ES (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 15 X 6 Shop Wheels

DODGE Wheel and Bolt Pattern 1990-92 DODGE MONACO (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 14 X 6 Shop Wheels
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

FORD Wheel and Bolt Pattern 2004 > FORD FREESTAR (VAN)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 15 X 6 Shop Wheels
 Hub Center Bore: 63.4 mm 2.5 inches
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

FORD Wheel and Bolt Pattern 2004-07 FORD FREESTAR (VAN)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.4 mm 2.5 inches

FORD Wheel and Bolt Pattern 1986 > FORD TAURUS (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 15 X 7 Shop Wheels
 Hub Center Bore: 63.4 mm 2.5 inches
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

FORD Wheel and Bolt Pattern 1986-06 FORD TAURUS (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.4 mm 2.5 inches

FORD Wheel and Bolt Pattern 1997 FORD TAURUS SHO (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 16 X 7 Shop Wheels
 Hub Center Bore: 63.4 mm 2.5 inches
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

FORD Wheel and Bolt Pattern 2002-06 FORD T-BIRD (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.4 mm 2.5 inches

FORD Wheel and Bolt Pattern 2002 > FORD THUNDERBIRD (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 16 X 7 Shop Wheels
 Hub Center Bore: 63.4 mm 2.5 inches
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

FORD Wheel and Bolt Pattern 1989-97 FORD THUNDERBIRD, SC (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 15 X 6 Shop Wheels
 Hub Center Bore: 63.4 mm 2.5 inches
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

FORD Wheel and Bolt Pattern 1994-03 FORD WINDSTAR (VAN)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 15 X 6 Shop Wheels
 Hub Center Bore: 63.4 mm 2.5 inches

JAGUAR Wheel and Bolt Pattern 1999 > JAGUAR S-TYPE (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 16 X 7 Shop Wheels
 Hub Center Bore: 63.4 mm 2.5 inches
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

JAGUAR Wheel and Bolt Pattern 2003 > JAGUAR S-TYPE R BREMBO BRAKES (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.4 mm 2.5 inches
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

JAGUAR Wheel and Bolt Pattern 2003-08 JAGUAR S-TYPE R BREMBO BRAKES (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.4 mm 2.5 inches

JAGUAR Wheel and Bolt Pattern 1999-08 JAGUAR S-TYPE, 2.5 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.4 mm 2.5 inches

JAGUAR Wheel and Bolt Pattern 2004 > JAGUAR XJ (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 74.1 mm 2.92 inches
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

JAGUAR Wheel and Bolt Pattern 2004-08 JAGUAR XJ, XJ8, XJ8L, VANDAN PLAS (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.8 mm 2.51 inches

JAGUAR Wheel and Bolt Pattern 2007-08 JAGUAR XK (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.8 mm 2.51 inches

JAGUAR Wheel and Bolt Pattern 1997-06 JAGUAR XK8 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 1/2-RH
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 8 Turns

Shop Lug Nuts

 Hub Center Bore: 74.1 mm 2.92 inches

JAGUAR Wheel and Bolt Pattern 2007-08 JAGUAR XKR (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.8 mm 2.51 inches

JAGUAR Wheel and Bolt Pattern 2002 > JAGUAR X-TYPE (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.4 mm 2.5 inches
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

JAGUAR Wheel and Bolt Pattern 2002-08 JAGUAR X-TYPE, 2.5, 3.0, VDP, SPORT WAGON (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.4 mm 2.5 inches

LAND ROVER Wheel and Bolt Pattern 2008 LAND ROVER LR2 (TRUCK/VAN/SUV)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 14 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 85 to 95 lb-ft.
Minimum Thread Engagement: 8 Turns

Shop Lug Nuts

 Hub Center Bore: 63.4 mm 2.5 inches


LINCOLN Wheel and Bolt Pattern 1988-03 LINCOLN CONTINENTAL (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.4 mm 2.5 inches

LINCOLN Wheel and Bolt Pattern 1988-97 LINCOLN CONTINENTAL (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 15 X 6 Shop Wheels
 Hub Center Bore: 63.4 mm 2.5 inches

LINCOLN Wheel and Bolt Pattern 1999 > LINCOLN LS (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 16 X 7 Shop Wheels
 Hub Center Bore: 63.4 mm 2.5 inches

LINCOLN Wheel and Bolt Pattern 1999-06 LINCOLN LS (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.4 mm 2.5 inches

LINCOLN Wheel and Bolt Pattern 1993 > LINCOLN MARK VIII (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 16 X 7 Shop Wheels
 Hub Center Bore: 63.4 mm 2.5 inches

LINCOLN Wheel and Bolt Pattern 1993-98 LINCOLN MARK VIII (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.4 mm 2.5 inches

MERCURY Wheel and Bolt Pattern 1989-97 MERCURY COUGAR (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 15 X 6 Shop Wheels
 Hub Center Bore: 63.4 mm 2.5 inches

MERCURY Wheel and Bolt Pattern 2004 > MERCURY MONTEREY (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 14 X 6 Shop Wheels
 Hub Center Bore: 63.4 mm 2.5 inches

MERCURY Wheel and Bolt Pattern 2004-07 MERCURY MONTEREY (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.4 mm 2.5 inches

MERCURY Wheel and Bolt Pattern 1986 > MERCURY SABLE (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 15 X 6 Shop Wheels
 Hub Center Bore: 63.4 mm 2.5 inches

MERCURY Wheel and Bolt Pattern 1986-05 MERCURY SABLE (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 63.4 mm 2.5 inches

MERCURY Wheel and Bolt Pattern 1986-92 MERCURY SABLE (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 14 X 6 Shop Wheels
 Hub Center Bore: 63.4 mm 2.5 inches

OLDSMOBILE Wheel and Bolt Pattern ALL OLDSMOBILE 605, 607 (TRUCK/VAN/SUV)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size:
Torque Sequence: 1, 3, 5, 2, 4

Shop Lug Nuts

 Hub Center Bore: 65.0 mm 2.56 inches

PEUGEOT Wheel and Bolt Pattern ALL PEUGEOT 605, 607 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
Torque Sequence: 1, 3, 5, 2, 4

Shop Lug Nuts

 OEM Wheel Size: 15 X 6 Shop Wheels
 Hub Center Bore: 65 mm 2.56 inches

PORSCHE Wheel and Bolt Pattern 2002 > PORSCHE BOXSTER (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 17 X 8 Shop Wheels
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

VOLVO Wheel and Bolt Pattern 1979-94 VOLVO 200 SERIES (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 1/2-RH
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 8 Turns

Shop Lug Nuts

 OEM Wheel Size: 14 X 6 Shop Wheels
 Hub Center Bore: 65.1 mm 2.56 inches
 Wheel Offset:  M = Medium Offset typically RWD (Rear Wheel Drive) +20 offset

VOLVO Wheel and Bolt Pattern 2004.5-08 VOLVO 40 SERIES 5-LUG (MID-YEAR CHANGES) (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 65.1 mm 2.56 inches

VOLVO Wheel and Bolt Pattern 2001 > VOLVO 60 SERIES (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 14 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 85 to 95 lb-ft.
Minimum Thread Engagement: 8 Turns

Shop Lug Nuts

 OEM Wheel Size: 16 X 6.5 Shop Wheels
 Hub Center Bore: 65.1 mm 2.56 inches
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

VOLVO Wheel and Bolt Pattern 2001-08 VOLVO 60 SERIES (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 14 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 85 to 95 lb-ft.
Minimum Thread Engagement: 8 Turns

Shop Lug Nuts

 Hub Center Bore: 65.1 mm 2.56 inches

VOLVO Wheel and Bolt Pattern 1997 > VOLVO 70 SERIES (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.75b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 16 X 6.5 Shop Wheels
 Hub Center Bore: 65.1 mm 2.56 inches
 Wheel Offset:  M = Medium Offset typically RWD (Rear Wheel Drive) +20 offset

VOLVO Wheel and Bolt Pattern 1997-08 VOLVO 70 SERIES (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.75b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 65.1 mm 2.56 inches

VOLVO Wheel and Bolt Pattern 1985-92 VOLVO 740 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 14 X 6 Shop Wheels
 Hub Center Bore: 65.1 mm 2.56 inches
 Wheel Offset:  M = Medium Offset typically RWD (Rear Wheel Drive) +20 offset

VOLVO Wheel and Bolt Pattern 1983-90 VOLVO 760 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 15 X 6 Shop Wheels
 Hub Center Bore: 65.1 mm 2.56 inches
 Wheel Offset:  M = Medium Offset typically RWD (Rear Wheel Drive) +20 offset

VOLVO Wheel and Bolt Pattern 1983-91 VOLVO 780 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 15 X 6 Shop Wheels
 Hub Center Bore: 65.1 mm 2.56 inches
 Wheel Offset:  M = Medium Offset typically RWD (Rear Wheel Drive) +20 offset


VOLVO Wheel and Bolt Pattern 1997 > VOLVO 80 SERIES (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 14 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 85 to 95 lb-ft.
Minimum Thread Engagement: 8 Turns

Shop Lug Nuts

 OEM Wheel Size: 16-17 Shop Wheels
 Hub Center Bore: 65.1 mm 2.56 inches
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

VOLVO Wheel and Bolt Pattern 1997-08 VOLVO 80 SERIES 1 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 14 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 85 to 95 lb-ft.
Minimum Thread Engagement: 8 Turns

Shop Lug Nuts

 Hub Center Bore: 65.1 mm 2.56 inches

VOLVO Wheel and Bolt Pattern 1994 > VOLVO 850, 850 TURBO (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 16 X 6.5 Shop Wheels
 Hub Center Bore: 65.1 mm 2.56 inches
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

VOLVO Wheel and Bolt Pattern 1997 > VOLVO 90 SERIES (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 16 X 6.5 Shop Wheels
 Hub Center Bore: 65.1 mm 2.56 inches
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

VOLVO Wheel and Bolt Pattern 1991-95 VOLVO 940 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 15 X 6 Shop Wheels
 Hub Center Bore: 65.1 mm 2.56 inches
 Wheel Offset:  M = Medium Offset typically RWD (Rear Wheel Drive) +20 offset

VOLVO Wheel and Bolt Pattern 1991-96 VOLVO 940 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 65.1 mm 2.56 inches

VOLVO Wheel and Bolt Pattern 1992-97 VOLVO 940 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 65.1 mm 2.56 inches

VOLVO Wheel and Bolt Pattern 1995 > VOLVO 960 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 65.1 mm 2.56 inches

VOLVO Wheel and Bolt Pattern 1995-97 VOLVO 960 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.75b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 OEM Wheel Size: 15-16 Shop Wheels
 Hub Center Bore: 65.1 mm 2.56 inches
 Wheel Offset:  M = Medium Offset typically RWD (Rear Wheel Drive) +20 offset

VOLVO Wheel and Bolt Pattern 2008 VOLVO C30 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 65.1 mm 2.56 inches

VOLVO Wheel and Bolt Pattern 2005-08 VOLVO V50 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 12 X 1.5
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 75 to 85 lb-ft.
Minimum Thread Engagement: 7 Turns

Shop Lug Nuts

 Hub Center Bore: 65.1 mm 2.56 inches

VOLVO Wheel and Bolt Pattern 2000-08 VOLVO V70 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 14 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 85 to 95 lb-ft.
Minimum Thread Engagement: 8 Turns

Shop Lug Nuts

 Hub Center Bore: 65.1 mm 2.56 inches

VOLVO Wheel and Bolt Pattern 2003 > VOLVO V70XC (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 14 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 85 to 95 lb-ft.
Minimum Thread Engagement: 8 Turns

Shop Lug Nuts

 OEM Wheel Size: 16 Shop Wheels
 Hub Center Bore: 65.1 mm 2.56 inches
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

VOLVO Wheel and Bolt Pattern 2001-08 VOLVO XC70 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 14 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 85 to 95 lb-ft.
Minimum Thread Engagement: 8 Turns

Shop Lug Nuts

 Hub Center Bore: 65.1 mm 2.56 inches

VOLVO Wheel and Bolt Pattern 2003 > VOLVO XC90 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 14 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 85 to 95 lb-ft.
Minimum Thread Engagement: 8 Turns

Shop Lug Nuts

 OEM Wheel Size: 16-18 Shop Wheels
 Hub Center Bore: 65.1 mm 2.56 inches
 Wheel Offset:  H = High Positive typically FWD (Front Wheel Drive) +45, 40, 35 offsets

VOLVO Wheel and Bolt Pattern 2003-08 VOLVO XC90 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 14 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 85 to 95 lb-ft.
Minimum Thread Engagement: 8 Turns

Shop Lug Nuts

 Hub Center Bore: 65.1 mm 2.56 inches

VOLVO Wheel and Bolt Pattern 2001-05 VOLVO XR70 (CAR)

 Bolt Pattern: M: 5 X 108  S: 5 X 4.25
      Wheel Spacers / Adapters
 Stud Size: 14 X 1.5b
Torque Sequence: 1, 3, 5, 2, 4
Torque Specs: 85 to 95 lb-ft.
Minimum Thread Engagement: 8 Turns

Shop Lug Nuts

 Hub Center Bore: 65.1 mm 2.56 inches


Additional Wheel / Measurement Information


Wheel Bolt Pattern GaugeKey Identifying Wheel Dimensions: Wheel Bolt or Lug Pattern (or bolt circle, lug circle, lug pattern, etc.) is the measured diameter of an imaginary circle formed by the centers of the wheel lugs or bolt holes. Bolt patterns can be 3, 4, 5, 6, 7, 8 or 10 lug holes. A bolt circle of 5 x 4.5 would indicate a 5 lug bolt pattern on a circle with a diameter of 4.5 inches, for example.

Identifying Wheel Dimensions

There are four important measurements that are used to categorize and identify a wheel for fitment purposes. Wheel Dimensions
  1. Rim Diameter This is the actual diameter of the wheel at the point where the tire bead seats (NOT the outer lip of the rim).
  2. Rim Width Measure this from the inside of the outer lip at the bead seating point to the inner lip.
  3. Back Spacing A very important measurement, it’s from the inside of the wheel at the point where it contacts the hub, brake drum or axle flange to the inside edge (lip) of the wheel.
  4. Bolt Pattern Count the number of mounting holes for the wheel and determine the diameter of a circle that would run through their center. On an even number wheel (e.g. 4, 6, 8 or 10 lug wheel), it’s a direct measurement. On an odd number wheel (e.g. 3, 5 or 7 lug wheel), you can measure from the CENTER of one hole to the OUTER EDGE of the hole diagonally across from it.

How To Measure Wheel Bolt Pattern

Use the number of lugs and the bolt circle:

If there is an EVEN number of lugs: Measure center-to-center on lugs directly across from each other. If there is an ODD number of lugs: Measure from the CENTER of one lug to the OUTER EDGE of the hole diagonally across from it.

Measure Bolt Pattern

Lug Nuts and Torque

Lug Nuts and Torque

Torque Sequence:

4 Lug Nut / Bolt Pattern Torque Sequesnce 5 Lug Nut / Bolt Pattern Torque Sequesnce 6 Lug Nut / Bolt Pattern Torque Sequesnce 8 Lug Nut / Bolt Pattern Torque Sequesnce 10 Lug Nut / Bolt Pattern Torque Sequesnce Wheel Bolt Torque and Stretch

All alloy wheels should be installed using a torque wrench. This ensures that the wheels are not too tight or too loose. Check your vehicle’s manual for correct settings. When you install wheels for the first time, you should re-torque wheels after about 100km to 150km (60 to 90 miles). Always refer to Owner’s Manual for proper factory specifications that take precedence over the listed recommendations. 12mm = 70~80, 7/16 = 55~65, 1/2 = 75~85, 14mm = 85~95, 9/16 = 95~115, 5/8 = 135~145.

More Info: The Importance of Torquing Lug Nuts / Bolts

Hub Center Bore

Hub Centerbore Measurements

Hub Center Bore: Relates to the center hole in the wheel that centers the wheel on the hub of the car. Since most wheels are mass produced, they have a large center bore to accommodate several different vehicles. If this is the case, it is recommended that you use a hub ring. Hub rings are hard plastic or metal ring that fits between the wheel and the vehicle. This centers the wheel perfectly on the hub ensuring that there is no run out when the wheel is installed on to the vehicle. Without hub rings it is possible to get vibrations even if the wheel / tire assembly is perfectly balanced.

Wheel Offset

Wheel offset is the distance from the mounting surface of the wheel to the true center line of the rim. A positive offset means the mounting surface of the wheel is positioned in front of the true center line of the rim / tire assembly. This in effect brings the tire in to the fender well more. Conversely, a negative offset means the mounting surface of the wheel is behind the true center line of the rim / tire assembly. This will cause the tire to stick out away from the vehicle.

Wheel Offset

H = High - Positive Offset, typically FWD (Front Wheel Drive) +45, 40, 35 offsets

M = Medium - Neutral Offset, typically RWD (Rear Wheel Drive) +20 offset

L = Low - Zero to Negative Offset, Offset typically RWD (Rear Wheel Drive) 0 offset

Wheel and Tire How To Videos:

How to Install Wheel Spacers and Wheel Adapters

How to Install Wheel Spacers / Adapters Find more like this... 6:57 More Videos...

How to Measure Wheel Back Spacing

How to Measure Wheel Back Space Find more like this... 6:31 More Videos...

How to Measure and Calculate Wheel Offset

How to Measure and Calculate Wheel Offset Find more like this... 3:10 More Videos...

Helpful Wheel, Rim and Tire Resources:

Common Bolt Pattern Conversions

4-100
4x3.94
4-108
4x4.25
4-110
4x4.33
4-114.3
4x4.5
5-100
5x3.94
5-108
5x4.25
5-110
5x4.33
5-112
5x4.41
5-114.3
5x4.5
5-115
5x4.52
5-120
5x4.72
5-120.7
5x4.75
5-127
5x5
5-130
5x5.12
5-135
5x5.3
5-139.7
5x5.5
6-114.3
6x4.5
6-127
6x5
6-135
6x5.3
6-139.7
6x5.5
8-165.1
8x6.5
8-170
8x6.69

How to Measure Bolt Pattern Bolt pattern - diameter of an imaginary circle formed by the centers of the wheel lugs.

Wheel Lug Nut / Bolt Torque Sequence Correct Wheel Lug Nut / Bolt Torque Sequence - 4 lug, 5 lug, 6 lug.

How to Measure Wheel Back Spacing This measurement is important to be sure you have proper wheel clearance.

How To Read A Tire Sidewall Learn to understand the common markings found on tire sidewalls.

Wheel, Tire and Fender Fitment Calculator Calculate Wheel Fitment, Tire Stretch and Rolling Radius. Includes Speedometer Error Calculator. Play with specs, try different settings and combinations, compare results.

Wheel Bolt Pattern GaugeTire Size Change / Speedometer Calibration Calculator This calculator is designed to give information related to tire size changes and the general impact they have on the calibration of a speedometer. It determines speedometer error and tire size information based on published and generally accepted tire dimensions as given by the standard US tire system (i.e. 205/45-ZR16). All calculations are based on the assumption of a new tire (as opposed to used) where the numbers on the tire accurately represent the dimensions.


This information is accurate to the best of our knowledge. No warranties or guarantees are expressed or implied as to the accuracy of the information provided on this site. Use of this site constitutes your agreement to these terms.


Legend



Hub Center Bore: Relates to the center hole in the wheel that centers the wheel on the hub of the car. Since most wheels are mass produced, they have a large center bore to accommodate several different vehicles. If this is the case, it is recommended that you use a hub ring. Hub rings are hard plastic or metal ring that fits between the wheel and the vehicle. This centers the wheel perfectly on the hub ensuring that there is no run out when the wheel is installed on to the vehicle. Without hub rings it is possible to get vibrations even if the wheel / tire assembly is perfectly balanced.

Torque: All alloy wheels should be installed using a torque wrench. This ensures that the wheels are not too tight or too loose. Check your vehicle's manual for correct settings. When you install wheels for the first time, you should re-torque wheels after about 100km to 150km (60 to 90 miles). Always refer to Owner's Manual for proper factory specifications that take precedence over the listed recommendations. 12mm = 70~80, 7/16" = 55~65, 1/2" = 75~85, 14mm = 85~95, 9/16" = 95~115, 5/8" =135~145.

Bolt Pattern: Also lug pattern or bolt circle, is the diameter of an imaginary circle formed by the centers of the wheel lugs. Bolt patterns can have 3, 4, 5, 6, 8 or 10 lug holes. The bolt pattern is comprised of two numbers - the first indicates how many bolt holes are on the wheel, and the other describes how far apart they are. for example, a bolt circle of 5x108 would indicate a 5 lug bolt pattern in a circle with a diameter of 108mm.

Dual Bolt Pattern: More and more manufacturers are building their wheels with two bolt patterns. This expands the number of fitments the wheel applies to. For example: a wheel with a 4-100/114.3 bolt pattern has 8 lug holes and will fit both 4-100mm and 4-114.3mm fitments.

Wheel Plus Sizing

Plus sizing your wheel & tire combination was designed to enhance vehicle performance and looks by allowing fitment of larger diameter rims and lower profile tires. The theory is that while making these changes, you keep the overall tire diameter within 3% of the original equipment tires. This is important because larger variances can cause problems with transmission shift points which can decrease fuel mileage. It can also confuse braking system computers which can even lead to brake failure.

Here's the rule of thumb for "plus sizing":

Plus 1:

  • Increase section width by 10mm
  • Decrease aspect ratio by 10 points
  • Increase rim diameter by 1 inch

Plus 2:

  • Increase section width by 20mm
  • Decrease aspect ratio by 20 points
  • Increase rim diameter by 2 inches.

Learn More About Wheel Plus Sizing




Most Popular

Bolt Pattern Cross Reference - Wheel Swaps
Wheelbase Cross Reference - Body Swaps
Transmission Cross Reference
How To Build Your Own Hot Rod
Project Cars and Part Donor Cars For Sale
Hot Rod Tech, References and Information

Popular Tags

Bolt Pattern ~  Builds ~  Calculator ~  Carburetor ~  Chassis / Body Swaps ~  Customizations ~  Differential ~  Dimensions ~  DIY ~  Driving ~  Engine ~  Featured ~  Glass ~  Hot Rod Parts ~  How To ~  Projects ~  Rat Rod ~  Rat Rod Parts ~  Rear-End ~  Roadkill Show ~  Tech Info ~  Wheel & Tire ~  Wheel Swap ~  Wiring Diagrams

Categories

AUTOMOTIVE BASICS ~  BATTERY & CHARGING ~  BODY WORK ~  BRAKES ~  CHASSIS & DRIVE TRAIN ~  COOLING SYSTEM ~  ELECTRICAL & LIGHTING ~  ENGINE ~  EXHAUST ~  FUEL SYSTEM ~  IGNITION SYSTEM ~  PAINT AND PINSTRIPING ~  PERFORMANCE ~  STEERING & SUSPENSION ~  TRANSMISSION ~  WHEEL & TIRE

Resources by Manufacturer

BUICK ~  CADILLAC ~  CHEVROLET ~  CHRYSLER ~  DESOTO ~  DODGE ~  FORD ~  FRAZER ~  GMC ~  HUDSON ~  KAISER ~  LINCOLN ~  MERCURY ~  MOPAR ~  NASH ~  OLDSMOBILE ~  PACKARD ~  PLYMOUTH ~  PONTIAC ~  STUDEBAKER ~  WILLYS

How To & DIY Guides

  • GM B-Body Chassis Narrowing for Body Swap

    How To Narrow a GM B-Body Chassis

    0
    The General Motors 4th Generation B-Body Platform is perfect for a lot of 40s, 50, and 60s cars and trucks, [Read More...]
  • How To Make PVC Train Horns at Home
    How To Make PVC Train Horns at Home
    0
  • Install Transmission Temperature Gauge
    How To Install A Transmission Temperature Gauge
    0
  • Automotive Paint Troubleshooting Causes and Cures
    How To Troubleshoot Automotive Paint: Causes and Cures
    0
  • How to Give Your Old Car a New Look
    How to Give Your Old Car a New Look
    0

Technical Info and Tools

  • Common Firing Orders

    Common Firing Orders

    0
    MSD Ignition created this helpful chart that display many common V8 firing orders and distrubutor direction for AMC, Buick, Chevy, Chrysler, Ford, GM, Oldsmobile, and Pontiac. [Read More…]
  • Mopar Engine Block Numbers
    Mopar Engine Block Numbers
    0
  • Automotive Vacuum Gauge Engine Tests
    How To Diagnose Common Engine Problems with a Vacuum Gauge
    0
  • Differential Rear-End Gear Calculator
    Differential Gear Ratio Calculator
    0
  • Chevrolet Engine Block Numbers
    Chevrolet Engine Block Numbers
    0
Menu
  • Automotive Basics
  • Build Your Own Hot Rod
  • Customizations
  • Hot Rod Lifestyle
  • Hub Cap Mart
  • Emblem Mart
  • Driving
Stay Connected



Get eMail Updates
No Spam, No BS.
Just What's New at Roadkill Customs...

Email Format
Contact Us
  • Phone: 480-331-7457
  • Send a Message
Roadkill Enterprises
  • Roadkill Customs

  • Roadkill Imports

  • Roadkill Motors

  • Rockabilly Life

© 1996-2018 Roadkill Customs ~ Web Development by ISM interactive
